4 inch / 100 mm
Borewell Submersible Pumpset

Technical Specifications

SMF	X Series	N Series
Power Rating	2.0 - 7.5 hp	2.0 hp
Head Range	8 - 78 m	7.5 - 31 m
Discharge Range	120 - 480 lpm	120 - 450 lpm
Phase	1Ø (2-5hp) \| 3Ø (3-7.5hp)	1Ø (2hp)
Voltage	230/415 V	200 V
Speed	2800 rpm	2800 rpm

Salient Features

Energy efficient motors and pumps
Wide operating voltage band
All casing are in superior FG 260 grade
Heavy duty journal and tilting thrust bearings
Optimized diaphragm design
Motor filled with anti-corrosive solution
Rubber & Metal clad Rubber bushes are provided for intermediate journal support
Three layer protection to avoid sand entry into motor
SS clad top & bottom intermediate shells

Applications

Open, Sprinkler, Drip and lift Irrigation
large multistoried apartments
Industrial water supply
Individual residences
