Centrifugal Jet Monobloc Pumpset

Technical Specifications

*Available in NX series

Power Rating	1.0 hp
Head Range	10 - 44 m
Discharge Range	348 - 1350 lph
Voltage	240 V (-15% to +6%)
Speed	2850 rpm
Min.Opr.Pressure	1.5 - 2.5 Bar

Salient Features

A totally enclosed, Fan-cooled (TEFC) motor
Dinamically balanced rotor
Wide voltage band 180V to 240V, 50Hz single phase supply
Superior grade rigid cast iron construction
Deep groove ball bearings used drive & Non-drive end
Casing & impeller made of Noryle & cast iron FG 260
Carbon vs ceramic mechanical seal
Jet pressure valve unit

Applications

Domestic water supply
Large Multistoried Apartments
Fountains, Lawns and Gardens
Lifting water from sump to overhead tanks
